PIGMENT BLUE 15:1/ HP BLUE 4387

PIGMENT BLUE 15:1/ HP BLUE 4387

C.I.NO.: PB15:1

Advantage:

Main Application Recommended: Plastics

Description

Product Description – PB15:1

HP BLUE 4387 (PIGMENT BLUE 15:1) is a phase-stabilized a-copper phthalocyanine blue. It shows good resistance to organic solvents, excellent lightfastness and weatherfastness, superior migaration fastness. It is mainly used in plastic industries,and paints industries sometimes.

Recommended Application

Coatings: solvent based coatings, water based coatings, industrial coatings, powder coatings
Plastics: PP, PE, PVC, PS/SAN, ABS, PC, POM, PA, PET, PBT, PMMA, Rubber/TPV, SBC, TPO, TPU

Technical Data:

Product Information
Chemical TypePhtlaoCAS NO.12239-87-1
C. I. NamePigment Blue 15:1EINECS / ELINCS NO.205-685-1
C. I. Constitution No.74160Chemical FormulaC32H16CuN8
Technical Performance
Full ShadeTint
Weather Resistance54~5Heat Stability °C240°C
Light Fastness87
Physical Properties
Physical FormPowderBleeding in Xylene4
Specific Density (g/cm3):1.55 ± 0.1Bleeding in Methyl Ethyl Ketone4
Specific Surface(㎡/g):55 ± 10Bleeding in Ethyl Acetate5
Oil Absorption55 ± 10Bleeding in Cellosolve5
pH Value6.0~8.0Bleeding in Mineral Turpentine5
Volatile Matter1% maxResistance to Acid5
Resistance to Alkali5
Packaging
25kgs/bag 400kgs/Pallet
StorageShelf Life5 years
Should be stored in cool, dry and ventilate place.
TRANSPORTATION
Avoid inversion, sunlight, moisture and crash. Avoid damage the package.
  • Light fastness: Light fastness rating is assessed on 1 to 8 Blue Wool scale where 1 = ‘Poor’ and 8 = ‘Excellent’.
  • Heat Stability : Heat stability values given indicate the maximum temperature at which the pigment can be stoved for 10 min. on the full shade and in reductions without undergoing any significant change in shade.
  • Oil absorption: The oil absorption is determined on the basis of EN ISO 787-5 and given in g linseed oil per 100 gm. pigment.
  • Solvent bleeding: The bleeding in solvents is tested using the powder grades and the visual rating given on 1 to 5 Grey scale
    where 1 = ‘Heavy bleeding’ and 5 = ‘No bleeding”

Disclaimer – The information given in this data sheet is based on the present state of our knowledge & is intended as a general description of our products & their possible applications. Due to the multitude of formulations, production & application conditions, all the above mentioned data have to be adjusted to the circumstances of the processor. No liabilities, including those for patent rights, can be derived from this fact for individual cases. It cannot be ruled out that this product contains particles < 0.1 μm. Any user of this product is responsible for determining the suitability of Sudarshan’s products for its particular application & to ensure that any proprietary rights & existing laws & legislation are observed.
