PIGMENT YELLOW 65/ HP YELLOW 1679

PIGMENT YELLOW 65/ HP YELLOW 1679

C.I.NO.: PY65

Advantage: High color strength, Reddish

Main Application Recommended: Road Mark paints

Description

Product description – PY65

HP Yellow 1679 (PIGMENT YELLOW 65) exhibits a reddish-yellow shade and excellent hiding power. It bears certain similarities to high-hiding-power P.Y.74, with comparable performance in solvent resistance, recrystallization fastness in solvent-containing media, lightfastness, and durability. Its applicable media include air-drying paints and emulsion paints.

Recommended Application

Coatings: Road Mark paints, solvent based coatings, water based coatings, industrial paints

Technical Data:

Product Information
Chemical TypeMonoazoCAS NO.6528-34-3
C. I. NamePigment Yellow 65EINECS / ELINCS NO.229-419-9
C. I. Constitution No.11740Chemical FormulaC18H18N4O6
Technical Performance
Full ShadeTint
Weather Resistance54~5Heat Stability °C150°C
Light Fastness76~7
Physical Properties
Physical FormPowderResistance to Acid5
Specific Density (g/cm3):1.28-1.51Resistance to Alkali5
Specific Surface(㎡/g):20
Oil Absorption40-60
pH Value6.0-7.0
Volatile Matter1% max
Packaging
25kgs/bag   400kgs/Pallet
StorageShelf Life5 years
Should be stored in cool, dry and ventilate place.
TRANSPORTATION
Avoid inversion, sunlight, moisture and crash. Avoid damage the package.
  • Light fastness: Light fastness rating is assessed on 1 to 8 Blue Wool scale where 1 = ‘Poor’ and 8 = ‘Excellent’.
  • Heat Stability : Heat stability values given indicate the maximum temperature at which the pigment can be stoved for 10 min. on the full shade and in reductions without undergoing any significant change in shade.
  • Oil absorption: The oil absorption is determined on the basis of EN ISO 787-5 and given in g linseed oil per 100 gm. pigment.
  • Solvent bleeding: The bleeding in solvents is tested using the powder grades and the visual rating given on 1 to 5 Grey scale
    where 1 = ‘Heavy bleeding’ and 5 = ‘No bleeding”

Disclaimer – The information given in this data sheet is based on the present state of our knowledge & is intended as a general description of our products & their possible applications. Due to the multitude of formulations, production & application conditions, all the above mentioned data have to be adjusted to the circumstances of the processor. No liabilities, including those for patent rights, can be derived from this fact for individual cases. It cannot be ruled out that this product contains particles < 0.1 μm. Any user of this product is responsible for determining the suitability of Sudarshan’s products for its particular application & to ensure that any proprietary rights & existing laws & legislation are observed.
